6015
Hydraulic mining shovels
Mining excavator of the 140-tonne class: Cat C27 engine in the Tier 1 equivalent build from Caterpillar's regional sheet for Africa, the Middle East and Eurasia; buckets 5.8–12 m³.
- Passport
- Operating weight
- 140 000 kg
- Engine power
- 599 kW
- ISO 9249
- Bucket capacity
- 5.8–12.0 m³
Specification
| Operating weight | 140 000 kg |
|---|---|
| Engine power | 599 kW ISO 9249 |
| Bucket capacity | 5.8–12.0 m³ |
| Engine | Cat C27 |
| Max. digging depth | 8 000–8 800 mm |
| Max. reach | 13 900–14 700 mm |
|---|---|
| Emission standard | Tier 1 equivalent |
| Transport width | 5 689 mm |
| Transport height | 4 903 mm |
Source6015 Hydraulic Mining Shovel Technical Specifications — AEXQ3041-01 (08-2025), Replaces AEXQ3041, Build Number: 04C (Glo · read 2026-09-08 · Build 04C; regional sheet for Africa, the Middle East and Eurasia
